D-Link DAP-1320 User Manual

13D-Link DAP-1320 User Manual
Section 3 - Conguration
8. If your wireless device does not support WPS, click Select this
option if you want to set up your network manually.
Click Next to continue.
9. Wait while your device scans for available Wi-Fi networks. You will
see a list of networks found. Select the Wi-Fi Network you wish to
use, and click Select.
Note: If the network you would like to connect to is not listed, click
Back and select the manual option again to perform another scan.
Make sure you are in range of your wireless router.
7. Press and hold the WPS button on your wireless router or access
point until the light starts blinking green and then release. Allow
up to two minutes for the WPS process to nish. When a connection
is successfully established, the LED on the device should turn solid
green.
Note: Refer to your router or access point’s user manual instructions
for the WPS process.
WPS Button

D-Link DAP-1320 Specifications

Wireless Standards and Antennas

wireless standards	IEEE 802.11n, IEEE 802.11g
antenna type	2 Internal Antennas

Weight and Dimensions

dimensions	1.89” x 1.65” x 2.11” (4.8 x 4.19 x 5.36 cm)
weight	0.152 lb (68.94g)
