DAP-1610 AC1200 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Parameter Description
Wi-Fi Network
Network name (SSID)
A name for the wireless network. The name can consist of digits and
Latin characters.
Hide SSID
If the switch is moved to the right, other users cannot see your Wi-Fi
network. It is recommended not to hide the network in order to
simplify initial configuration of the wireless network.
BSSID
The unique identifier for this wireless network. You cannot change
the value of this parameter, it is determined in the device's internal
settings. The field is displayed in the settings of the existing wireless
network.
Max associated clients
The maximum number of devices connected to the wireless network.
When the value 0 is specified, the device does not limit the number
of connected clients.
Broadcast wireless
network
If the switch is moved to the left, devices cannot connect to the
wireless network. Upon that the extender can connect to another
access point as a wireless client.
Clients isolation
Move the switch to the right to forbid wireless clients of this
wireless network to communicate to each other.
Page 45 of 91
