32
Section 3 - Conguration
Network Settings
This page lets you configure the network settings for the DAP-X1870. To access this page, click the Settings drop-down menu at
the top of the page, then select Network. Click Save at any time to save the changes you have made on this page.
Management Link You can change the URL name of the device by editing the text
in the text box. If you change the name of the device, you will
need to enter “http://xxxx.local.” (where “xxxx” corresponds to
the name of the device) in the address bar of your web browser
in order to access the conguration utility.
Advanced Settings
The Advanced Settings section of the Network Settings page allows you to
configure both IPv4 and IPv6 settings that will be used by the DAP- X1870’s
extended network.
IPv4
My LAN Connection is Here you can select whether you want the IP to have a
Dynamic IP or Static IP address. If you select Dynamic IP, the
options below will not be available.
IP Address Enter the Static IP address that you want to assign to the
extended network AP. This address should be outside of the
uplink router’s DHCP address pool.
Subnet Mask Enter the subnet mask.
Gateway Address
Enter the gateway address. This is usually the IP address of
the uplink router.
Primary DNS Server Enter the address of the primary DNS server.
Secondary DNS Server Enter the address of the secondary DNS server. This is optional
but will provide backup if the primary server fails.
