D-Link DGS-1510 Series Hardware Installation Guide

DGS-1510 Series Gigabit Ethernet SmartPro Switch Hardware Installation Guide
16
Figure 1–13 Side panels view of a DGS-1510-20 Switch
Figure 1–14 Side panels view of a DGS-1510-28 Switch
Figure 1–15 Side panels view of a DGS-1510-28P Switch
Figure 1–16 Side panels view of a DGS-1510-52 Switch
Smart Fans
The DGS-1510 Series Switches includes smart fans that will automatically change their speed
depending on the internal temperature detected by the sensors built-in the Switch’s hardware. These
smart fans support three states. They can either be off, running at a low speed, or running at a high
speed.
The following will explain when these fans will toggle between low and high speeds:
• DGS-1510-20: When the internal temperature, detected by the sensor, rises above 47°C, the fan
will automatically change to the high speed. When the internal temperature, detected by the
sensor, falls below 43°C, the fan will automatically change to the low speed.
• DGS-1510-28: When the internal temperature, detected by the sensor, rises above 48°C, the fan
will automatically change to the high speed. When the internal temperature, detected by the
sensor, falls below 43°C, the fan will automatically change to the low speed.

D-Link DGS-1510 Series Specifications

General

Layer	Layer 2+
IGMP Snooping	Yes
Static Routing	Yes
Humidity	10% to 90% non-condensing
Series	DGS-1510
Type	Smart Managed Switch
VLAN Support	Yes
QoS	Yes
Management	Web-based, CLI, SNMP
Power Supply	Internal
MAC Address Table	16K entries
802.3ad Link Aggregation	Yes
Spanning Tree Protocol (STP)	Yes, STP/RSTP/MSTP
Jumbo Frame Support	Yes, up to 9KB
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p
