DGS-3630 Series Layer 3 Stackable Managed Switch Hardware Installation Guide
62
1
NC
NC
2
GND
GND
3
GND
GND
4
GND
GND
5
GND
GND
6
+12V
+12V
7
+12V
+12V
8
+12V
+12V
9
NC
Power Present
10
NC
Power Good
11
Power Present
NC
12
Power Good
NC
13
NC
NC
14
+12V
+12V
22-pin DC power cable
Figure Error! Use the Home tab to apply AppendixHeading to the text that you want to appear here.-2 Redundant Power Supply
(RPS) 22-pin DC Power Cable
RPS 22-pin DC Power Cable Pin Assignments
Pin
Device
DPS-700
1
-54Vrtn
-54Vrtn
2
-54V
-54V
3
+12V
+12V
4
+12V
+12V
5
+12V
+12V
6
+12V
+12V
7
NC/GND
GND
