DI-634M User’s Manual
D-Link Systems, Inc.
Getting Started
Getting Started
Please remember that D-Link Wireless 108G MIMO devices are pre-configured to
connect together, right out of the box, with their default settings.
For a typical wireless setup at home (as shown above), please do the following:
You will need broadband Internet access (a Cable or DSL-subscriber line into
your home or office)
Consult with your Cable or DSL provider for proper installation of the modem.
Connect the Cable or DSL modem to the DI-634M Wireless Broadband Router
(see the printed Quick Installation Guide included with your router).
If you are connecting a desktop computer to your network, install the D-Link
DWL-G520M wireless PCI adapter into an available PCI slot on your desktop
computer. You may also install the DWL-G510 or DWL-G520 (See the printed
Quick Installation Guide included with the network adapter).
Install the D-Link DWL-G650M wireless Cardbus adapter into a notebook
computer. (See the printed Quick Installation Guide included with the
DWL-G650M.
)
Install the D-Link DFE-530TX+ adapter into a desktop computer. The four Ethernet
LAN ports of the DI-634M are Auto MDI/MDIX and will work with both straight
through and cross-over cable. (See the printed Quick Installation Guide included
with the DFE-530TX+.)
