DIR-806A Wireless AC750 Multi-Function Router
User Manual
Configuring Device (Router Mode)
Creating Static IP WAN Connection
To create a connection of the Static IP type, click the Add button on the Net / WAN page. On the
opened page, select the Static IP value from the Connection Type drop-down list and specify
the needed values.
Figure 75. The page for creating a new connection. The General settings and Ethernet sections.
Parameter Description
General settings
Interface
A physical or virtual interface to which the new connection will be
assigned.
Name
A name for connection for easier identification.
Enable
Select the checkbox to enable the connection.
Direction
The direction of this connection.
Ethernet
MTU
The maximum size of units transmitted by the interface.
Page 99 of 233
