7D-Link DPR-1260 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
WLAN LED
A solid light indicates that the wireless
segment is ready. This LED blinks during
wireless data transmission.
LAN LED
A solid light indicates connection on
the LAN port. This LED blinks during
data transmission.
Power LED
A solid light indicates a proper
connection to the power supply.
USB LEDs (1-4)
A solid light indicates connectivity to an USB
printer or scanner.
