D-Link DSL-2600U User Manual

DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
The VLAN section is displayed for the PPPoE, Static IP, Dynamic IP, and Bridge connection
types.
Parameter Description
VLAN
Allow to create several
connections assigned
to this port
Select the checkbox to allow the router to use several untagged
connections.
Use VLAN
Select the checkbox to allow the router to use tagged VLAN
connections.
VLAN ID
An identifier for the VLAN. The field is displayed when the Use
VLAN checkbox is selected.
VLAN priority
A priority tag for the type of traffic transmitted. The field is
displayed when the Use VLAN checkbox is selected.
The Miscellaneous section is displayed for all connection types except for Bridge.
Figure 54. The page for creating a new connection. The Miscellaneous section.
Parameter Description
Miscellaneous
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Page 59 of 112

D-Link DSL-2600U Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz - 60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps
IEEE 802.11b wireless transfer rates	11, 5.5, 2, and 1Mbps
IEEE 802.11g wireless transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Interfaces

ADSL interface connector	RJ-11
LAN interface port	RJ-45
LAN interface standard	10/100BASE-T Ethernet
