DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
LAN
To configure the router's local interface, proceed to the Net / LAN page.
Figure 61. The page for configuring the local interface.
If needed, edit the basic parameters of the local interface.
Parameter Description
IP Address
The IP address of the router in the local subnet. By default, the
following value is specified: 192.168.1.1.
Netmask
The mask of the local subnet. By default, the following value is
specified: 255.255.255.0.
IGMP snooping
The IGMP snooping function provides management of multicast
traffic in the LAN. Select the needed choice of the radio button:
Blocking: the router does not let multicast traffic pass to the LAN.
Standard: the router lets multicast traffic pass to the LAN devices
which request such traffic. Recommended for better performance of
the LAN.
Off: the router lets multicast traffic pass to all devices from the
LAN. Default value.
When needed settings are configured, click the Save button.
In the Static DHCP section, you can specify MAC address and IP address pairs (set a fixed IP
address in the local area network for a device with a certain MAC address). The router assigns IP
addresses in accordance with the specified pairs only when the DHCP server is enabled (in the
DHCP server section, in the Mode drop-down list, the Enable value is selected).
Page 66 of 112
