D-Link DSL-2600U User Manual

DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
Advanced
In this menu you can configure advanced settings of the router:
• enable the UPnP function
• define interface groups and allow the router to connect to a private Ethernet line
• configure a DDNS service
• add name servers
• define static routes
• edit the ADSL connection parameters
• create rules for remote access to the web-based interface.
UPnP
On the Advanced / UPnP page, you can enable and disable the UPnP function.
UPnP is a set of networking protocols designed for automatic configuration of network devices. The
UPnP function performs automatic configuration of the device's parameters for network
applications requiring an incoming connection to the router.
Figure 72. The Advanced / UPnP page.
If you want to manually specify all parameters needed for network applications, deselect the
Enabled checkbox and click the Change button.
If you want to enable the UPnP function in the router, select the Enabled checkbox and click the
Change button.
Page 81 of 112

D-Link DSL-2600U Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz - 60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps
IEEE 802.11b wireless transfer rates	11, 5.5, 2, and 1Mbps
IEEE 802.11g wireless transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Interfaces

ADSL interface connector	RJ-11
LAN interface port	RJ-45
LAN interface standard	10/100BASE-T Ethernet
