DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
Parameter Description
Dial on demand
Select the checkbox if you want the router to establish connection to
the Internet on demand. In the Maximum idle time field, specify a
period of inactivity (in seconds) after which the connection should
be terminated.
PPP IP extension
This option is used by some ISPs. Contact your ISP to clarify if this
checkbox needs to be enabled.
Use Static IP Address
Select the checkbox if you want to use a static IP address to access
the Internet. In the Static IP Address field displayed when the
checkbox is selected, specify a static IP address.
PPP debug
Select the checkbox if you want to log all data on PPP connection
debugging.
PPPoE pass through
Select the checkbox if you want to allow PPPoE clients of
computers from your LAN to connect to the Internet through this
PPPoE connection of the router.
The IP section is displayed for the Static IP and Dynamic IP connection types.
Figure 60. The page for creating a new connection. The IP section.
Parameter Description
IP
IP Address
Displayed for the Static IP type only.
Enter an IP address for this WAN connection.
Netmask
Displayed for the Static IP type only.
Enter a subnet mask for this WAN connection.
Gateway IP Address
Displayed for the Static IP type only.
Enter an IP address of the gateway used by this WAN connection.
Vendor ID
Displayed for the Dynamic IP type only.
The identifier of your ISP. Optional.
When all needed settings are configured, click the Save button.
Page 65 of 112
