D-Link DSL-2600U User Manual

DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
When the WPA-PSK or WPA2-PSK value is selected, the WPA Encryption settings section is
displayed:
Figure 66. The WPA2-PSK value is selected from the Network Authentication drop-down list.
Parameter Description
Encryption Key PSK
A key for WPA encryption. The key can contain digits and/or Latin
characters.
WPA2 Pre-
authentication
The checkbox activating preliminary authentication (displayed only
for the WPA2-PSK authentication type).
WPA Encryption An encryption method: TKIP, AES, or TKIP+AES.
WPA renewal
The time period (in seconds), at the end of which a new key for
WPA encryption is generated. When the value 0 is specified for this
field, the key is not renewed.
When you have configured the parameters, click the Change button.
Page 72 of 112

D-Link DSL-2600U Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz - 60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps
IEEE 802.11b wireless transfer rates	11, 5.5, 2, and 1Mbps
IEEE 802.11g wireless transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Interfaces

ADSL interface connector	RJ-11
LAN interface port	RJ-45
LAN interface standard	10/100BASE-T Ethernet
