DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
To activate the WPS function, select the WPS Enable checkbox and click the Change button.
When the checkbox is selected, the Information and Connection sections are available on the
page.
Parameter Description
WPS Status
The state of the WPS function:
• Configured (all needed settings are specified)
• Unconfigured (you need to specify the relevant settings).
SSID The name of the router's WLAN.
Network Authentication
The network authentication type specified for the WLAN.
Encryption The encryption type specified for the WLAN.
Device PIN
The PIN code of the router. This parameter is used when connecting
the router to a registrar to set the parameters of the WPS function.
Client PIN
The PIN code of the device newly connected to the router via the
WPS function.
WPS Method
A method of the WPS function. Select a value from the drop-down
list.
PIN: Connecting the device via the PIN code.
PBC: Connecting the device via the push button (actual or virtual).
PIN Code
The PIN code of the WPS-enabled device that needs to be connected
to the wireless network of the router.
The field is displayed only when the PIN value is selected from the
WPS Method drop-down list.
Connect
Click the button to connect the wireless device to the router's WLAN
via the WPS function.
Page 77 of 112
