DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
You can specify the following parameters:
Parameter Description
Name
A name for the group for easier identification. You can specify any
name.
LANs
The list of available internal interfaces is displayed in the left
column of the line.
Use the button ==> to select interfaces. The selected interfaces will
be displayed in the right column of the field.
WANs
WAN connections to which the new group will be assigned. WAN
connections of PPPoA and IPoA type cannot be added to groups.
Use the button ==> to select WAN connections. The selected
connections will be displayed in the right column of the field.
Click the Save button.
!
When you add an interface to the new group, it is excluded from the group to which it has
been assigned before.
To edit or remove an existing group, select the relevant group on the Advanced / Interface
grouping page. On the page displayed, change the parameters and click the Save button, or click
the Delete button. When you delete a group, interfaces assigned to it are reassigned to the
DEFAULT group.
Page 83 of 112
