D-Link DSL-4320L User Manual

6D-Link DSL-4320L User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 2 3 4
5
6 7 8
1 DSL Port Connect to an DSL-enabled telephone line and with the supplied microlter/splitter.
2 USB 3.0 Port Connect a USB ash drive to share content , or connect it to a USB printer to share it on your network.
3 USB 2.0 Port Connect a USB ash drive to share content , or connect it to a USB printer to share it on your network.
4 Reset Button Insert a paperclip in the hole and wait for several seconds to reset the router to default settings.
5 WPS Button Press to start the WPS process and automatically create a secure connection to a WPS client.
6 Gigabit LAN Ports (1-4) Connect Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
7 Power Button Press the power button to power on and o.
8 Power Connector Connector for the supplied power adapter.

D-Link DSL-4320L Specifications

Device Interfaces

USB Port Power	5 V / 0.9 A
802.11 ac/n/g/b/a wireless LAN	5 V / 0.9 A

Operating Environment

Operating Temperature	0 to 40 °C (32 to 104 °F)
Operating Humidity	10% to 95% maximum (non-condensing)

Power

Input Voltage	100 to 240 V AC, 50/60 Hz
Output Voltage	12 V DC
Output Current	5 A

Weight and Dimensions

weight	925.08 g (2.04 lbs)
dimension 1	225.20 mm (8.87 inches)
dimension 2	342.70 mm (13.49 inches)
dimension 3	100.88 mm (3.97 inches)
