D-Link DSL-4320L User Manual

79D-Link DSL-4320L User Manual
Section 4 - Conguration
ATM
Select the ATM interface from the drop-down menu.
Enter the Virtual Path Indicator (0 - 255).
Enter the Virtual Channel Indicator (32 - 65535).
Select the latency from the drop-down menu.
Select the method of encapsulation provided by your ISP. You can
select LLC or VCMUX.
Select the Quality of Service type from the drop-down menu.
Click Save when you are done.
Interface:
VPI:
VCI:
Latency:
Encapsulation:
ATM QoS:
On this page you can congure your Asynchronous Transfer Mode (ATM) settings. If you are unsure, you can obtain these settings from your ISP.

D-Link DSL-4320L Specifications

Device Interfaces

USB Port Power	5 V / 0.9 A
802.11 ac/n/g/b/a wireless LAN	5 V / 0.9 A

Operating Environment

Operating Temperature	0 to 40 °C (32 to 104 °F)
Operating Humidity	10% to 95% maximum (non-condensing)

Power

Input Voltage	100 to 240 V AC, 50/60 Hz
Output Voltage	12 V DC
Output Current	5 A

Weight and Dimensions

weight	925.08 g (2.04 lbs)
dimension 1	225.20 mm (8.87 inches)
dimension 2	342.70 mm (13.49 inches)
dimension 3	100.88 mm (3.97 inches)
