D-Link DSL-4320L User Manual

46D-Link DSL-4320L User Manual
Section 3 - Getting Started
Tap on the document icon to view documents.
Tap the camera icon to view pictures.
Tap on the movie icon to play videos.
Tap on the music icon to play audio les.
Tap on the folder icon to browse all les in a folder
view.
Tap on the star icon to access your favorite les.
Note: Available features may dier depending on the Android OS version of
your device.
Main Menu
The mydlink SharePort main menu has dierent sections that let you see all the documents, photos, movies, or music stored on
your removable storage. Tap < or >, or swipe left or right to move between the dierent sections. The Wi-Fi icon at the bottom
indicates an active local network connection (blue) or remote connection (green/red). Tap Log In if it is not lit, or Log Out to
return to the login page.

D-Link DSL-4320L Specifications

Device Interfaces

USB Port Power	5 V / 0.9 A
802.11 ac/n/g/b/a wireless LAN	5 V / 0.9 A

Operating Environment

Operating Temperature	0 to 40 °C (32 to 104 °F)
Operating Humidity	10% to 95% maximum (non-condensing)

Power

Input Voltage	100 to 240 V AC, 50/60 Hz
Output Voltage	12 V DC
Output Current	5 A

Weight and Dimensions

weight	925.08 g (2.04 lbs)
dimension 1	225.20 mm (8.87 inches)
dimension 2	342.70 mm (13.49 inches)
dimension 3	100.88 mm (3.97 inches)
