D-Link DSL-4320L User Manual

12D-Link DSL-4320L User Manual
Section 2 - Installation
6
7
If connecting to the DSL-4320L wirelessly, access the wireless utility on your computer or mobile device. Scan
for available Wi-Fi networks (SSID). Select and join a Wi-Fi network and use the password which corresponds
to the information on the supplied Wi-Fi Conguration Card.
Press the power button and verify that the power LED is lit. Allow 1 minute for the router to boot up.
Wi-Fi Conguration Note

D-Link DSL-4320L Specifications

Device Interfaces

USB Port Power	5 V / 0.9 A
802.11 ac/n/g/b/a wireless LAN	5 V / 0.9 A

Operating Environment

Operating Temperature	0 to 40 °C (32 to 104 °F)
Operating Humidity	10% to 95% maximum (non-condensing)

Power

Input Voltage	100 to 240 V AC, 50/60 Hz
Output Voltage	12 V DC
Output Current	5 A

Weight and Dimensions

weight	925.08 g (2.04 lbs)
dimension 1	225.20 mm (8.87 inches)
dimension 2	342.70 mm (13.49 inches)
dimension 3	100.88 mm (3.97 inches)
