D-Link DSL-4320L User Manual

44D-Link DSL-4320L User Manual
Section 3 - Getting Started
DSL-4320L
1. Make sure the device is powered on. Then plug your USB drive into
the USB port of the device.
Note: If you connect a removable storage with many les or a large capacity, it may
take a while for the router to scan and catalog your les.
2. Use your Android mobile device to search for and download the free
mydlink SharePort app from Google Play™.
If you have a QR code reader, you can scan the code for mydlink
SharePort to the right.
3. On your mobile device, go to your Wi-Fi settings and connect to your
router’s wireless network using the default Wi-Fi settings. Locate the
Wi-Fi name (SSID) and password for your device as printed on the
included Wi-Fi Conguration Card.
Using mydlink SharePort in a local network:

D-Link DSL-4320L Specifications

Device Interfaces

USB Port Power	5 V / 0.9 A
802.11 ac/n/g/b/a wireless LAN	5 V / 0.9 A

Operating Environment

Operating Temperature	0 to 40 °C (32 to 104 °F)
Operating Humidity	10% to 95% maximum (non-condensing)

Power

Input Voltage	100 to 240 V AC, 50/60 Hz
Output Voltage	12 V DC
Output Current	5 A

Weight and Dimensions

weight	925.08 g (2.04 lbs)
dimension 1	225.20 mm (8.87 inches)
dimension 2	342.70 mm (13.49 inches)
dimension 3	100.88 mm (3.97 inches)
