D-Link DSL-4320L User Manual

48D-Link DSL-4320L User Manual
Section 3 - Getting Started
Tap on a le to start the document viewer. In the viewer:
•Tap the screen to bring up zoom in/out buttons.
•Drag the screen up or down to scroll between pages.
•Tap
to perform File, Find, Zoom, Reading View, Go To
Page, and Bookmarks actions.
Note: Available actions may dier depending on your Android OS.

D-Link DSL-4320L Specifications

Device Interfaces

USB Port Power	5 V / 0.9 A
802.11 ac/n/g/b/a wireless LAN	5 V / 0.9 A

Operating Environment

Operating Temperature	0 to 40 °C (32 to 104 °F)
Operating Humidity	10% to 95% maximum (non-condensing)

Power

Input Voltage	100 to 240 V AC, 50/60 Hz
Output Voltage	12 V DC
Output Current	5 A

Weight and Dimensions

weight	925.08 g (2.04 lbs)
dimension 1	225.20 mm (8.87 inches)
dimension 2	342.70 mm (13.49 inches)
dimension 3	100.88 mm (3.97 inches)
