D-Link Ethernet Broadband Router DIR-100 User Manual

DIR-100 Ethernet Broadband Router
2. In the Control Panel menu, click Network and Internet Connections.
3. In the Network and Internet Connections menu, click Network Connections.
Click Network Connections.
Click Network and Internet
Connections.
4. In the Network Connections menu, right-click on Local Area Connection, then click Properties.
58

D-Link Ethernet Broadband Router DIR-100 Specifications

General

Category	Wireless Router
Model	DIR-100
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet
WAN Ports Qty	1
LAN Ports Qty	4
Standards	IEEE 802.3, IEEE 802.3u
Ports	4 x 10/100Base-TX LAN, 1 x 10/100Base-TX WAN
Security	NAT
Power	5 V DC
Operating Temperature	0 - 40 °C
Storage Temperature	-20 °C to 70 °C
Humidity	10 - 90% non-condensing
