8D-Link DAP-3666 User Manual
Hardware Overview
Connections
No. Item Description
1 Mounting Lock Connector for the mount screw.
2 Reset Button Press and hold for 10 seconds to factory reset the device.
3 LAN Port Connect to a switch or router via an Ethernet cable.
4 LAN (PoE) Port
Connect to a Power over Ethernet (PoE) switch or router
via an Ethernet cable.
LEDs
No. Item LED Color Description
1
Power/ Status
LED
Red (Solid)
Indicates that the DAP-3666 has
malfunctioned.
Red (Flashing)
Indicates the DAP-3666 is booting up
or malfunctioning.
Green (Solid)
Indicates that the DAP-3666 is
working properly.
