D-Link Nuclias Connect DAP-3666 User Manual

87D-Link DAP-3666 User Manual
Web User Interface
Limit Administrator
VLAN ID
Check the box and the enter the specic VLAN
ID that the administrator will be allowed to log
in from.
Limit Administrator IP Check the box to enable the limit administrator
IP address.
IP Range Enter the IP address range that the
administrator will be allowed to log in from and
then click Add.
Note: To save the new conguration settings to the rmware, click
Conguration > Save and Activate, otherwise click Discard Changes to
delete any setting change.
Limit Administrator
Check one or more of the eight main categories to display the various hidden administrator parameters and settings displayed on the next ve
pages. Each of the eight main categories display various hidden administrator parameters and settings.
System Name Settings
System Name Enter the name of the device. The default name
is D-Link DAP-3666.
Location Enter the physical location of the device, e.g.
72nd Floor, D-Link HQ.
MDNS Name Enter the name of the multicast DNS. The
default name is dap3666.
Note: To save the new conguration settings to the rmware, click
Conguration > Save and Activate, otherwise click Discard Changes to
delete any setting change.

D-Link Nuclias Connect DAP-3666 Specifications

General

Device Type	Wireless Access Point
MU-MIMO	Yes
PoE	802.3af PoE
Management	Nuclias Connect
VLAN Support	Yes
Operating Humidity	10% to 90% non-condensing
Wireless Standard	802.11ac
Frequency Band	2.4 GHz, 5 GHz
Ethernet Port	1 x Gigabit Ethernet
Mounting	Wall or Ceiling
Operating Temperature	0 to 40 °C
Wireless Security	WPA, WPA2, WPA3
Maximum Data Rate	1200 Mbps (867 Mbps on 5 GHz + 300 Mbps on 2.4 GHz)
Antenna	Internal
