D-Link Nuclias DNH-100

Nuclias Connect Software User Manual Nuclias Connect Conguration
Page 46
WAN Metrics UL Speed
(kps)
The uplink speed of the WAN connection set in kbps. If the uplink
speed is not known set to 0.
Network Auth Type Choose from drop-down menu the network authentication type
and specify the web-address.
IP Address Type
Availability
Choose from drop-down menu the IP address version and type
that the Hotspot Operator uses and that would be allocated and
available to a mobile device after it authenticates to the network.
Click Delete icon to delete it from the list.
Domain Name List one or more domain names for the entity operating the AP.
Roaming Consortium Add service providers or groups of roaming partners whose security
credentials can be used to connect to a network. Click Delete icon
to delete it from the list.
Nai Realm Specify list of all NAI realms available through the BSS. Click subtract
icon to delete it from the list.
EAP Method Specify one or more EAP methods and its authentication ID and
Parameter type. Click Delete icon to delete it from the list.
RFC 4282 Click on drop-down menue to enable or disable RFC 4282.
3gpp Cellular Network Specify a list of the 3GPP cellular networks available through the AP.
Spcify the MCC and MNC, then click Add icon. Click Delete icon to
delete it from the list.
Connection Capability Specify a list of common IP protocols (TCP, UDP, IPsec) and ports
(21, 80, 443, 5060), specify its port number and the status of the IP
protocol and click Add. Click Delete icon to delete it from the list.
Operator Friendly Name Identies the Hotspot venue operator and choose its language.
OSU SSID Specify OSU SSID name.
OSU Server URI Specify OSU Server URI
OSU Method Specify a list of OSU methods by choosing its language and then
specifying a method by clicking Add. Click Delete icon to delete it
from the list.
OSU Cong Choose from drop-down menu the OSU Congu.
OSU Language Code Choose a language from the drop-down menu.
OSU Friendly Name Choose a language from the drop-down menu and specify the OSU
friendly name.
OSU Nai Specify the OSU NAI.
OSU Service Description Specify a service description for the OSU.
OSU Icon Language Code Specify from drop-down menu the language of the icon.
OSU Icon File Path Specify location of icon le.
OSU Icon File Name Specify icon le name.
OSU Icon Width Specify width of the icon, in pixels.
OSU Icon Height Specify length of the icon, in pixels.
OSU Icon Type Speciy icon le type from the drop-down menu.
Click Add to save the values and update the screen.
Click Clear to reset all settings.
