MNL-000
07 [3]
Proprietary
and Confidential Page
54
of
63
26.14
HI Dose Narr
ow Band U
VB Maintenance Phase Pr
o
tocols:
1/WEEK
Maximum Number of Treatments = 4
ALL SKIN TYPES:
Dose should be held steady at last clearance phase dose
26.15
HI Dose Narr
ow Band U
VB T
reatment
Limits for M
aintenance &
As Requir
ed Pr
o
tocols
Skin Type
I
II
III
IV
V
VI
MED RANGE
50-300 mJ
100-400 mJ
150-500 mJ
200-600 mJ
250-700 mJ
300-800 mJ
DOSE LIMITS with WA
RNING
1100 mJ
2000 mJ
4400 mJ
6000 mJ
8200 mJ
9400 mJ
SYSTEM DOSE LIMITS
1500 mJ
3000 mJ
5500 mJ
8000 mJ
10500 mJ
12000 mJ
53
55
Table of Contents
Table of Contents
2
Introduction
5
Indications for Use
6
Classifications
6
Operating Specifications
6
Transport and Storage Specifications
7
EMC Precautions
7
Accuracy
7
Labels and Symbols
8
UV Risk Group 2 Labels (CE Devices Only)
10
Delivery and Inspection
11
Lamp Inspection
13
Site Selection
13
Training Requirements
13
Important Safeguards and Warnings
14
Unlocking the Device
16
Changing or Disabling the Key Code
16
Operating the Control Systems
16
Flex Dosimeter Instructions: UV Series
16
The Backup Time
17
Measuring the Power Output of Your Device
17
Setting up a Treatment
19
Special Functions of the Integrated Dosimeter
20
Special Notes
20
Flex Dosimeter Range and Accuracy
20
Flex Dosimeter Instructions: 1 Series
20
The Backup Time
21
Measuring the Power Output of Your 1 Series
21
Setting up a Treatment
23
Repeat Treatments
23
Special Functions of the Integrated Dosimeter
24
Special Notes
24
Flex Dosimeter Range and Accuracy
24
Flex Timer Instructions: UV Series, 7 Series, M Series, and
25
Series
25
Determining a Treatment Time
25
Setting up a Treatment Time
26
Special Functions of the Digital Timer
26
Special Notes
26
Flex Timer Range and Accuracy
27
Flex Timer Instructions: 1 Series
27
Determining a Treatment Time
27
Setting up a Treatment Time
28
Special Functions of the Digital Timer
28
Special Notes
28
Flex Timer Range and Accuracy
29
UV Series X and UV Series T Information
29
Domestic and Non-CE Electrical Requirements
29
European CE Electrical Requirements
30
Circuit Breaker
30
Unpacking and Assembly
30
How to Position the Patient
31
UV Series Lamp Removal and Replacement
31
Series X and 7 Series T Information
32
Electrical Requirements
32
Unpacking and Assembly
33
How to Position the Patient
34
Series Lamp Removal and Replacement
35
M Series X and M Series T Information
35
Electrical Requirements
35
Unpacking and Assembly
36
Special Notes
36
How to Position the Patient
37
M Series Lamp Removal and Replacement
37
Series Information
38
Electrical Requirements
38
Unpacking and Assembly
39
How to Position the Patient
39
Series Lamp Removal and Replacement
39
Series X and 1 Series T Information
40
Electrical Requirements
40
Unpacking and Assembly
41
How to Position the Patient
41
Hand and Foot Treatments
41
Larger Area Treatment
41
Series Lamp Removal and Replacement
42
Special Notes for 1 Series Units Equipped with Integrated Dosimetry
42
Treatment Distance
42
Calibration Output Certificate
43
Special Notes for 1 Series Units Equipped with the Digital Timer
43
Treatment Distances and Your Calibration Output Certificate
43
Treatment Protocols
45
UVA Clearing Phase Protocols (Skin Types I - III)
45
UVA Clearing Phase Protocols (Skin Types IV - VI)
47
UVA Maintenance Phase Protocols
49
UVA Treatment Limits for Maintenance & as Required Protocols
50
LO Dose Broad Band UVB Clearing Phase Protocols
50
LO Dose Broad Band UVB Maintenance Phase Protocols
50
Protocols
51
HI Dose Broad Band UVB Clearing Phase Protocols: 11011, 3/Week, 2/Week
51
HI Dose Broad Band UVB Maintenance Phase Protocols: 1/WEEK
51
LO Dose Narrow Band UVB Clearing Phase Protocols: 11011, 3/Week, 2/Week
52
LO Dose Narrow Band UVB Maintenance Phase Protocols: 1/WEEK
52
LO Dose Narrow Band UVB Treatment Limits for Maintenance & as Required Protocols
52
HI Dose Narrow Band UVB Clearing Phase Protocols
53
HI Dose Narrow Band UVB Maintenance Phase Protocols
54
HI Dose Narrow Band UVB Treatment Limits for Maintenance & as Required Protocols
54
Care of Your Phototherapy Unit
55
Recommended Maintenance Schedule
55
Cleaning/Disinfection
55
General Cleaning
55
Low-Level Disinfection
55
High-Level Disinfection
56
Resetting Your Lamp Hours
56
EMC Guidance
56
Flex Controller Trouble Shooting Guide
58
Power-On-Self-Test
58
Error Code E8Yz: Yz = Address of First Location with Range Error
59
Sensing Errors
59
Warranty and Contact Information
61
Limited Warranty Policy
61
Warranty Coverage
61
Customer Responsibility
62
Warranty Service
62
Disposal
62
Other Services
62
Contact Information
63
