3. Specifications
• Available sensor
1) Micro-voltage output sensor(mV)
2) Strain gage sensor(Bridge 350Ω, 120Ω).
• Maximum display
Max 32676
• A/D conversion
100 time/sec
• Temperature characteristics (Amp characteristics)
Zero : 1µV/℃
Span : 100ppm/℃
• Front panel
Measured value display : 7 segment 5 LED, Character height 10mm
State display LED : Red LED 2 pieces
Key switch : 4 pieces
• Various function
Convert function
: Possible for setting Upper limit(H1) & Lower limit(LO)
Contact capacity is AC 250V, 0.5A and DC 50V 1A.
Analog output : DC 0 ~ 10V.
• Option
① OP-01 : DC 4~20mA
② OP-02 : RS232C
③ OP-03 : RS485
3-1 General Specifications
• Power Supply : AC 220V, 60Hz, 0.5A (Standard Specifications)
• Temperature Range : -10℃∼60℃, less than 85% RH (where there is no dewing.)
• Size : 72 × 72 × 111 mm(W × H × D)
4
• Weight : about 700 g
