6. Setting Mode
6-1. Setting Method
If you push the key for about 3 seconds, will appear and then HL
will come out.
If you push the
key at that time, the setting mode will change in the following
direction, and if you push the key at that time, the setting mode will change in the
opposite direction. If you push the
key, the present mode will be chosen.
6-2. Setting Hi, Lo
You can set up the upper limit and lower limit of the relay output. HI will work if HI is
larger than the HI set value. LO will works if LO is smaller than the LO set value.
If you push the function key, the setting mode will come out.
If you push the Up key, you can choose ,
or (The upper limit -> , The lower limit -> )
If you push the ENT key, you choose HI or LO setting.
If you push the Shift key, you can choose the number location.
If you push the Up key, you can change the number as you wish.
….
You can save the setting value by pushing the ENT key.
-> -> or (In case it is not good, will come out.)
If you want to get out of the setting mode and return to the measurement mode,
you may have to push the Function key.
(Currently the value is indicated.)
6-3. Setting Decimal point
8
This product operates in a way of fixed decimal point, the decimal point must be
preset.
