#Option-02 (RS232C)
Make wire separately from power system wiring and noise wiring.
Make sure the use of sealed cable as a sensor cable.
Indicator Host PC
TX(Transmitting Data) RXD(Receiving Data), Number 2 Pin
RX(Receiving Data) TXD(Transmitting Data), Number 3 Pin
GN(Ground) GND(Ground), 5 Pin
1. TYPE : EIA-232C
2. Method : half duplex, asynchronous system
3. Baud-rate : Selection in 2400, 4800, 9600, 19200bps
4. Parity : No Parity
5. Data bit : 8 bit, No Parity
6. Stop bit : 1bit
7. Stream mode (Ex. Data +1234.5 transmission)
Data format (code : ASCII)]
CODE BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8
ASCII S T , N T , + 0
HEX 53H 54H 2CH 4EH 54H 2CH 2BH 30H
CODE BYTE9
BYTE10 BYTE11 BYTE12 BYTE13 BYTE14 BYTE15 BYTE16
ASCII 1 2 3 4 . 5 CR LF
HEX 31H 32H 33H 34H 2EH 35H 0DH 0AH
1) BYTE
. DATA S
1, BYTE2
TABLE: S T . DATA UnSTABLE
. DATA L
2) BYTE
: U S
OVERFLOW : O L . DATA UNDERFLOW : U
3 ~ BYTE6 : f ed
3) BYTE
4) BYTE CARR
5) BYTE LINE
ix character (, N T ,)
7 ~ BYTE14 : DATA 8 BYTE(+/-)
15 : IAGE RETURN
16 : FEED
17
8. Command mode : Please set to RS485 mode(OP-03:RS485 )
