3) DN-25W
At the time of purchasing sensor, the rated capacity (displacement) and rated output
(R.O) declared on the calibration sheet can be used for the calibration for easier
calibration.
DP-xx series (Half type (HBT) recommends setting the rated output value to
approximately 0.3300.
Refer to 8-5.Actual load calibration if you need to correct the error.
※ Zero position will change after setup is complete.
※Measuring Mode : The state in which the current measurement is being displayed
Measuring mode
While key is being Press, press key
Display Function mode
Display Sensor output value calibration mode
Display output type select mode
Display R.C. value(Rated capacity) input mode
Input the rated capacity value by using and key.
And then. Press
key
Calibration end
Select the sensor output type by using and key.
And then. Press
key
To Next Page
