Specifications for Solar 200W-V
Return to Master Table of Contents
REFERENCE DESCRIPTION DIMENSION
BOOM 5,700 mm (18' - 8'') 5,200 mm (17' - 1'')
ARM 2,900 mm
(9' - 6'')
2,400 mm
(7' - 10'')
2,400 mm
(7' - 10'')
2,000 mm
(6' - 7'')
BUCKET 0.75 0.75 0.75 0.75
A Maximum Digging
Radius
9,960 mm
(32' - 8'')
9,423 mm
(30' - 11'')
8,941 mm
(29' - 4'')
8,625 mm
(28' - 4'')
B Maximum Digging Depth 6,620 mm
(21' - 9'')
6,122 mm
(20' - 1'')
5,641 mm
(18' - 6'')
5,242 mm
(17' - 2'')
C Maximum Digging
Height
9,710 mm
(31' - 10'')
9,379 mm
(30' - 9'')
8,979 mm
(29' - 5'')
8,943 mm
(29' - 4'')
D Maximum Dump Height 6,887 mm
(22' - 7'')
6,511 mm
(21' - 4'')
6,112 mm
(20' - 1'')
6,042 mm
(19' - 10'')
