Daewoo Solar 200W-V - Engine Performance Curves (Per KS-R1004 Standard)

S0202040
Page 13
Specifications for Solar 200W-V
Return to Master Table of Contents
ENGINE PERFORMANCE CURVES (PER KS-R1004
STANDARD)
CONDITION SPECIFICATION
BAROMETIC PRESSURE 760 mm Hg (20°)
COOLING FAN 625.0 mm dia. (24.61 in. dia.), SUCKER
ALTERNATOR 24V x 50A
AIR CLEANER INSTALLED
MUFFLER INSTALLED
PERFORMANCE STANDARD KS R1004
POWER (MAX, RATED) 155.0 ps (152.88 hp) / 2200 rpm
MAX. TORQUE 56.0 kg•m (405.05 ft lbs) / 1600 rpm
FUEL CONSUMPTION(MIN,RATED) 166.0 g/ps•h (5.85 oz/Hp.h)
HAAA2700
Figure 4
