Daewoo Solar 200W-V - Brake System

S0202040
Page 20
Specifications for Solar 200W-V
Return to Master Table of Contents
Swing Bearing
Ty p e
Gear P.C.D
No. of Teeth
Ball Dia.
Race O.D.
Race Height
Static Thrust Load
Weight
Ball Bearing Internal Gear
Dia 1,104.0 mm (43.46 in.)
92
Dia 31.75 mm (1.25 in.)
Dia 1,327.0 mm (52.24 in.)
110.0 mm (4.33 in.)
420,860.0 kg (927,840 lbs.)
255.0 kg (560 lbs.)
Swing Performance
Max Swing Speed
Max Swing Torque
12.2 rpm
7,926.0 kg•m (57,328.85 ft lbs)
Brake
Control Type
Brake Torque
Brake Release Pressure
Pilot Pressure, Wet Disc
63.0 kg•m (455.68 ft lbs)
23.0 kg/sq cm (327 psi)
Swing Safety Lock
Type Manual Pin Locking
Motor Accessory
Brake Time Delayer
Make Up Valve Characteristic
5 (+3 / -0) Sec.
3 kg/cm2 (43 psi) at 120 l/min (31.7 gal/min)
BRAKE SYSTEM
Accumulator
Nitrogen Charge Pressure
Volume
30 kg/cm2 (427 psi)
0.7 l (0.73 qt)
Service Brake Valve
Max Output Pressure 80.0 kg/sq cm (1,140 psi)
Brake Filter
Filtration Rating
Bypass Valve Pressure
20 micron
6.0 kg/sq cm (85 psi)
System and Pressure
System
Service Brake Pressure
Brake Distance
Full Hydraulic, Dual Line
80.0 kg/sq cm (1,140 psi)
6.50 m (21' - 4'') at 24 km/h (15 mph)
