Daewoo Solar 200W-V - Steering System; Chocking System

S0202040
Page 21
Specifications for Solar 200W-V
Return to Master Table of Contents
STEERING SYSTEM
Steering Cylinder (Built-in Front Axle)
Bore Size
Rod Size
Stroke
Maximum Pressure
100.0 mm (3.94 in.)
50.0 mm (1.97 in.)
88.0 mm (3.46 in.)
180.0 kg/sq cm (2,560 psi)
CHOCKING SYSTEM
Chocking Valve
Maker & Model
Maximum Working Pressure
Check Valve Cracking Pressure
Make-up Pressure
HANIL, HIH1246
400 kg/cm
2
(5,689 psi)
2.0 kg/sq cm (28.4 psi)
3.0 kg/sq cm (42.7 psi)
Oscillating Angle
±
6.6
°
