Specifications for Solar 200W-V
Return to Master Table of Contents
TRAVEL SPEED TESTS
1. Block up all wheels securely.
2. Check that RPM at drive shaft is above
2,720 RPM at high speed and above
707 ± 30 RPM at low speed.
1. Travel Motor
2. Transmission
3. Propeller Shaft
4. Front Axle
5. Center Joint
Travel Mode Speed
High Speed 35 km/h (21.75 mph)
Low Speed 9 km/h (5.59 mph)
Figure 6
