Daewoo Solar 200W-V - Performance Tests and Standards; Standards

S0202040
Page 22
Specifications for Solar 200W-V
Return to Master Table of Contents
PERFORMANCE TESTS AND STANDARDS
STANDARDS
1. Main Relief Pressure
normal operation: 314 bar (4,550 psi)
with high travel "Pressure Up": 343 bar (4,974 psi)
2. Actuator Speeds
Operation Unit H Mode S Mode
Boom Up seconds 2.9 ± 0.3 3.2± 0.3
Down seconds 2.4 ± 0.3 2.4 ± 0.3
Arm Dump seconds 2.6 ± 0.3 2.9 ± 0.3
Crowd seconds 3.0 ± 0.3 3.4 ± 0.3
Bucket Dump seconds 2.1 ± 0.3 2.3 ± 0.3
Crowd seconds 2.5 ± 0.3 2.6 ± 0.3
Dozer Up seconds 1.9 ± 0.3 2.0 ± 0.3
Down seconds 1.6 ± 0.3 1.9 ± 0.3
Swing (3 Revolutions) seconds 14.7 ± 0.7 16.4 ± 0.7
Stabilizer Up seconds 3.5 ± 0.3 3.6 ± 0.3
Down seconds 3.1 ± 0.3 3.4 ± 0.3
Propeller Shaft High RPM (min) 2,720 ± 50
Low RPM (min) 707 ± 30
Breaking Distance m 6.50 m (21' - 4'') at 24 km/h (15 mph)
