17. Remove f our m ounting nuts fr om f our
corners of cabin floor (2, Figure 4).
18. Remove four he x bol ts (3, Fig ure 4) from
door side of cabin floor.
19. Remove two h ex bol ts ( 1, Figure 4) fr om
right s ide of cabin floor an d one bo lt ( 4)
under front window of cab floor.
20. Using a suitable lifting device, attach slings
to four lift points on top of cab (Figure 5).
NOTE:
Cab weig hs approximately 290
kg (639 lb).
21. Lift ca b fr om 2 5 - 5 0 mm ( 1" - 2") abo ve
deck hei ght. Chec k tha t all el ectrical
connections have bee n dis connected an d
all other items unbolted.
22. Continue lifting with the as sist cr ane to
remove the cab shell. Lower the shell to a
pre-prepared safe blocking support.
INSTALLATION
1. Using a suitable lifting device, attach slings
to four lift points on top of cab (Figure 5).
NOTE:
Cab weig hs approximately 290
kg (639 lb).
2. Lower cab into position on cab floor
Quantity Description
4 16 mm hex nuts at each
corner of the cab
4 10 mm x 1.5 hex bolts at
the door side of the cab
3 10 mm x 1.5 mm hex
head bolts, 2 on the right
side of the cab and 1
under the front window.
HAOF270L
2
1
3
4
Figure 4
Figure 5
Figure 6
