WINDOW AND GASKET REPLACEMENT
The c ab r emoval dr awing a lso s hows replacement gla ss an d mat ing win dow gas kets and r ubber tr im
pieces.
When replacing glass or weather-strip gaskets, always:
• Make sure the window frame and rubber trim section are both clean.
• Use soap and water to lubricate both the rubber and glass for assembly.
• A s harp, c urving me tal h ook an d/or a str aight, poi nted a wl c an b e he lpful i n e asing win dow
glass into position. Start from the bottom of the frame and work up.
IMPORTANT
When replacing window glass or making any type of structural repair to any part of the
operator’s cab, consider the cause of the damage and evaluate the potential for other threats or
hazards in the operating environment. Refer to “Falling Object Protective Structures (F.O.P.S.)”
on page -9 and make an evaluation to determine the need for additional protection for the
operator.
