FRONT 4–9
Fig. 14
Fig. 15
CAUTION : To prevent eye injury and burns when
welding, wear an approved welding helmet, gloves
and safety shoes.
• Increase the number of spot by 20% for areas to
be spot welded.
10.Apply the sealer tape.
• Apply the sealer tape to the hinge and brace
wheelhouse matching area as shown.
11.Weld the brace wheelhouse.
• Spot weld the brace wheelhouse as shown.
• Make MIG or gas welds at the door hinge areas.
3
7
6
6
6
2
2
1
2
2
5
12
3
7
5
7
3
3
11
6
1
1
11
4
2
2
WHEN REPLACING THE
FRONT SIDE ONLY.
3
3
5
2
5
3
2
6
1
12
1
7
5
11
3
SEALER TAPE
Fig. 16
12.Finish the welding areas.
• Use a hammer and dolly to even out the rear
wheelhouse and front longitudinal flanges for a
close fit with the surface of the front wheelhouse.
