- 9 -
4. STANDARD COMPOSITION AND ACCESSORIES
4.1 Standard Composition
٨The part names indicated in the boxes are standard parts. They are not supplied with this
welding machine. Preparation of the standard parts except the welding power source is
required to use the welding power source.
٨Input cable and grounding cable
For a switch box, the 2m input and grounding cables are from the back panel of welding power
source.
Input cable
AWG12 4mm
2
with 10mmǾ terminal x 3
Grounding cable
AWG12 4mm
2
with 10mmǾ terminal x 1
4.2 Accessory
Check the quantity of parts when opening the package.
Description Specification Q’ty Part No. Remarks
Power Cable connector DIX SK 50 1 4734-016
For base metal and holder
cable
4.3 Other Equipment
(1) TIG Welding
٨Use argon gas for welding with 99.9 % or more purity.
٨Use the proper filler wire for material, plate thickness, etc.
(2) STICK Welding
٨Use the proper stick welding electrode for purpose of use, welding position, shape of joint,
etc.
٨Use the electrode holder electrically insulated.
Basemetal
A
nalogremotecontrol㧔Optionallyavailable㧕
Digitalremotecontrol

㧔Optionallyavailable㧕
A
rgon
gas
3Ǿ400
V
Inputcables (2m)
Gas regulato
r
Weldingpowersource
Gashose
Weldingtorch
Torchswitch
Basemetalcable
Connecttothewater wastetreatmentequipment
orthewatercooler(whenusingthewater-cooledtorch)
Ground a work piece i
f
required by local law.

Water hose
Tap water or water cooler
(not needed for STICK welding
and for use of the air-cooled
torch)

