- 66 -
11. APPLIED FUNCTION (continued)
11.4.2 TIG filler wire feeding system
■Controller
Model
HC-71D
Rated input voltage Single phase 200/220V
VA at rated output 100VA
When you use HC-71D control box, CAN communication module(K5422B00) and CAN
communication cable(BKCAN-0405[5m] and BKCAN-0410[10m] ) are necessary separately.
■Wire guide assembly
Torch
Model of wire guide
AW(D)-18 BHCD-7118
AW(D)-26 BHCD-7126
AW(D)-17 BHCD-7117
࡮Model CM-7471 TIG FILLER wire feeder
11.4.3 Tungsten Electrode
Use cerium-Tungsten Electrode (grey mark) or thoriated tungsten electrode (red mark). Using
DAIHEN cerium-tungsten electrode that is hardwearing realizes good arc start and better work
efficiency.
■ Cerium-Tungsten Electrode
Part No.
Electrode Dimension(mm) Max. Tolerance Current(A)
Dia. Length DC Straight Polarity AC
0870-016 1.6 150 150 130
0870-024 2.4
150
250 220
0870-032 3.2
150
400 290
■ Thoriated Tungsten Electrode
Part No.
Electrode Dimension(mm) Max. Tolerance Current(A)
Dia. Length DC Straight Polarity AC
0831-005 0.5 150 20 -
0831-010 1.0
150
80 -
0831-016 1.6
150
150 130
0831-316 1.6 75 150 130
0831-020 2.0
150
200 180
0831-024 2.4
150
250 220
0831-324 2.4 75 250 220
0831-032 3.2 150 400 290
0831-332 3.2 75 400 290
0831-040 4.0 150 500 360

