- 75 -
13. PARTS LIST
٨Please contact your dealer to order parts. (See the back cover for telephone and fax numbers, and mailing
addresses.)
Symbol Part No. Description Specifications Q’ty Remarks
NF 4614-101 Circuit protector CB3-X0-10-072-42D-C 1
LF 4519-022 Line filter CF3030C-DJ 1
PL 100-0171 Pilot lamp N46010A7KW-01 (RoHS) 1
DR1 4531-204 DR&SCR complex module DFA75BA160 1
DR2 – 6 4531-308 High speed diode module DBA200UA60 4
DR7 100-0188 Diode D1N60-5060 1
TR1, 2 100-0198 IGBT module CM150DY-12NF-300G 2
TR3, 4 4534-407 IGBT module 2MBI150TA-060 2
TR5, 6 100-0194 IGBT module CM300DU-12F-300G 2
CT1 4810-030 CT W-W03029 1
CT2 4406-009 Hole current detector HA400S3EH 1
T1 P10535B00 Inverter transformer P10535B00 1
T2 W-W02936 Auto transformer W-W02936 1
C.C P10535C00 Coupling coil P10535C00 1
L1 P10525L00 DC reactor P10535L00 1
L2 4739-497 Ferrite core E04RA400270150 3
L3 4739-543 Ferrite core E04RA310190100 1
L4, 5, 6 4739-497 Ferrite core E04RA400270150 3
L7 4739-497 Ferrite core E04RA400270150 1
L8 4739-497 Ferrite core E04RA400270150 2
L9 – 14 4739-543 Ferrite core E04RA310190100 6
L15, 16 4739-543 Ferrite core E04RA310190100 2
L17 4739-543 Ferrite core E04RA310190100 1
L18 4739-497 Ferrite core E04RA400270150 2
THP1 4258-040 Thermostat 67L085 1 Side of DR2- 6
THP2 4614-051 Thermostat 67L090 1 Side of TR1- 4
THP3 4258-033 Thermostat 67L070 1 Side of TR5, 6
SOL 4813-046 Solenoid valve TYPE5511DC24V 1
FM1 P30016L00 Fan P30016L00 1
Lower side
(High speed type)
FM2 P10346L00 Fan P10346L00 1
Upper side
(Low speed type)
CR 4341-139 Relay G2R-1-T DC24V 1
SC1 – 8 100-0199 Surge clamper 1.5KE250CA-E3/1 8
R1 – 4 100-0175 Surge absorber ENE911D-14A 4
R5 Missing number
R6 4509-819 Cement resistor 40SH 200ΩJ 1
R7 4509-825 Cement resistor 20SH 15kΩJ 1
R8 – 13 100-0189 Carbon film resistor RD1/4W 1 kΩJ(RoHS) 6
R14 – 17 100-0192 Metal film resistor RNP-50SCZ00 10ΩF 4
R18a, b, c 4504-411 Non-inductive resistor NCRF24V 30ΩJ 3
R19a, b, c 4504-411 Non-inductive resistor NCRF24V 30ΩJ 3
To Next Page
