Users Manual
100
Select channels
Click OK.
Modifying a Channel Group
Double-click on a channel group, the Channel Group Modified interface is displayed.
You can modify channel group and click
OK to complete the settings.
Modify channel group
5.2.9 Quick Operation Bar
You can quickly access to the function modules on function titles and setting menu through shortcut
icons on quick operation bar.
This topic uses
ALARM and CAMERA an example to show you how to quickly access other modules.
Shortcut Icons on Function Titles
Click ALARM to enter the ALARM interface.
