Page #189 background imageLoading...
Page #189 background image
Users Manual
177
Table 5-41 Video quality analytics parameters
Parameter
Description
Stripe
A horizontal, vertical or diagonal stripe that might appear in the video
because of device aging or electronic interruption. Such stripe brings
visual interruption.
Noise
Video noises such as blurriness or quality reduction that is caused by
optical distortion or device problem during camera shooting.
Color Cast Variances in the normal proportions of RGB colors.
Defocus
Blurry video is caused during camera shooting, transferring and
processing. Such condition is a common image quality reduction
problem and defined as out of focus.
Overexposure
The video brightness refers to the intensity of image pixel. The range is
between 0 (the darkest black) and 255 (the brightest white). If the
brightness exceeds the threshold, the image is over exposed.
Click Apply to save the settings.
The system returns to the Video Quality Analytics interface.
Click Apply to complete the settings.
Click Default to restore the default setting.
5.10.5 System Events
You can configure the alarm output for three types of system event (HDD, Network, and User). When
there is an abnormal system event occurs, the system activates alarms in the way that you configure
in this section.
5.10.5.1 Configuring HDD Event Settings
Select Main Menu > ALARM > Exception > Disk.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua Technology DH-XVR1B16H and is the answer not in the manual?

Dahua Technology DH-XVR1B16H Specifications

General IconGeneral
Aspect ratio16:9
CertificationFCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product colorBlack
Rack capacity1U
Playback modesFast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup functionYes
Channels quantity16 channels
Multi-display modes4, 8, 9, 16
Video capturing speed60 fps
Maximum recording time1 h
Audio formats supportedAAC, G.711, PCM
Network connection typeRJ-45
Maximum video resolution3840 x 2160 pixels
Video compression formatsH.264, H.264+, H.265, H.265+
Analog signal format systemNTSC, PAL
Video capturing speed (PAL)30 fps
Playback resolutions supported3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports16
BNC output ports1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users128 user(s)
Ethernet interface typeFast Ethernet, Gigabit Ethernet
Supported network protocolsHTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interfaceSerial ATA
Maximum HDD capacity6000 GB
DC voltage12 V
Power supply typeDC
Power consumption (typical)10 W
Package weight1000 g
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)-10 - 45 °C
Storage relative humidity (H-H)0 - 90 %
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth236 mm
Width260 mm
Height48 mm
Weight860 g
