Users Manual
4
2.2.1 DH-XVR5108C-X/DH-XVR5104C-4KL-X/DH-XVR5104C-X/DH-
XVR4104C-X/DH-XVR4108C-X/DH-XVR5104C-X1/DH-XVR4104C-
X1/DH-XVR4108C-X1
Loosen the screws of the bottom of the chassis.
Loosen screws
Step 2 Place the HDD in accordance with the four holes in the bottom.
Align HDD
Step 3 Turn the device upside down and then secure the screws firmly.
