Users Manual
231
5.13.2 Configuring POS Settings
Select Main Menu > POS > POS Setting.
POS setting
Configure the settings for the POS parameters.
Table 5-56 POS parameters
Parameter
Description
POS Name
In the
POS Name
list, select the POS machine that you want to
configures settings for. Click to modify the POS name.
The POS name supports 21 Chinese characters or 63 English characters.
Enable Enable the POS function.
Record Channel
Select the channel(s) that you want to record. The selected channel(s)
starts recording after an alarm occurs.
The recording for POS alarms and auto recording function must be
enabled. For details, see "5.1.4.9 Configuring Recorded Video Storage
Schedule" and "5.9.1 Enabling Record Control."
Privacy Enter the privacy content.
Protocol
Select
POS
by default. Different machine corresponds to different
protocol.
