Dahua Technology DH-XVR1B16H User Manual

User’s Manual
1
1 Introduction
Overview
The Device is an excellent digital monitor product for security industry. The embedded LINUX OS
assures the stable operation. The H.265 and G.711 technologies assure the high quality image and low
bit stream. The frame-by-frame play function displays more details for analysis, and provides the
functions such as record, playback, and monitor and assures the synchronization for audio and video.
The Device also adopts the advanced control technology and great network data transmission
capability.
The Device adopts embedded design to achieve high security and reliability. It can work in the local
end and, with strong networking capability it can get connected to the professional surveillance
software (Smart PSS) to form a security network to show its powerful remote monitoring function.
The Device is applicable to the areas such as bank, telecom, electricity, traffic, intelligent residential
district, factory, warehouse, resources, and water conservancy facilities.
Functions
The functions might be different depending on the software and hardware version of the model you
purchased.
Smart Detection
 Smart detection: Effectively detect persons and motor vehicles in the video.
 Face detection: Effectively recognize faces in the video, analyze and carry out structured storage
of faces, and search faces quickly.
 Analyze IVS, carry out tripwire and zone intrusion analysis of persons and vehicles, and effectively
filter false report caused by tree leaves, rain and brightness changes.
Real-time Surveillance
 Support VGA port and HDMI port to realize the surveillance through monitors.
 Support HDMI, VGA, and TV output at the same time.
IoT Management
Provide specific management module for IoT features including humidity and temperature data
reports and alarms linkage.
Sensor Integration
Integrate coaxial cameras with diverse array of sensors such as temperature, humidity and wireless
alarm devices.
Storage Management

Dahua Technology DH-XVR1B16H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	16 channels
Multi-display modes	4, 8, 9, 16
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports	16
BNC output ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	236 mm
Width	260 mm
Height	48 mm
Weight	860 g
