Dahua Technology DH-XVR1B16H User Manual

User’s Manual
104
Table 5-20 Main menu description
No.
Icon
Description
1
Function
titles
Includes nine function titles:
SEARCH
,
ALARM
,
SMART DETECTION
,
POS
,
IoT
,
MAINTAIN
,
BACKUP, DISPLAY
and
AUDIO
. Click each title to open the
configuration interface of the title.
SEARCH
: Search for and play back the recorded video saved on the
Device.
ALARM
: Search for alarm information and configure alarm event actions.
SMART DETECTION
: Search SMD, face detection, and IVS information,
and configure related settings.
POS
: You can connect the Device to the POS (Point of Sale) machine and
receive the information from it.
IoT:
IoT live video preview, search, export reports, and configure function
settings.
MAINTAIN
: You can view log and system information, test network and
do other maintenance work.
BACKUP
: Search and back up the video files to the external storage
device such as USB storage device.
DISPLAY
: Configure the display effect such as displaying content, image
transparency, and resolution, and enable the zero-channel function.
AUDIO
: Manage audio files and configure the playing schedule. The
audio file can be played in response to an alarm event if the voice
prompts function is enabled.
2
Switch
icon
indicates the current page of main menu. Click to switch to the
next page or click or to turn page.
3
Setting
menu
Includes six configurations through which you can configure camera
settings, network settings, storage settings, system settings, account
settings, and view information.
4 Live
Click
to go to the live view screen.
5
When you point to , the current user account is displayed.
6
Click , select
Logout
,
Reboot
, or
Shutdown
according to your actual
situation.
7
Displays
Mobile Client
and
Device SN
QR Code.
Mobile Client: Use your mobile phone to scan the QR code to add the
device into the Cell Phone Client, and then you can start accessing the
Device from your cell phone.
Device SN: Obtain the Device SN by scanning the QR code. Go to the P2P
management platform and add the Device SN into the platform. Then
you can access and manage the device in the WAN. For details, refer to
the P2P operation manual. You can also configure P2P function in the
local configurations. See "5.1.4.5 Configuring P2P Settings."

Dahua Technology DH-XVR1B16H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	16 channels
Multi-display modes	4, 8, 9, 16
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports	16
BNC output ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	236 mm
Width	260 mm
Height	48 mm
Weight	860 g
