Dahua Technology DH-XVR1B16H - Page 19

User’s Manual
7
Connect to port
2.2.2.2 Installing HDD
Loosen the screws to take off the cover.
Loosen screws
Remove the screws to take off the bracket.
Take off bracket
Fix the HDD to the bracket and then connect power cable and data cable.
