Dahua Technology DH-XVR1B16H User Manual

User’s Manual
187
Parameter
Description
PTZ Linkage
Click
Setting
to display the PTZ interface.
Enable PTZ linkage actions, such as selecting the preset that you want to
be called when an alarm event occurs.
Face Detect can only link PTZ preset.
Post Record
Set a length of time for the Device to delay turning off recording after
the alarm is cancelled. The value ranges from 10 seconds to 300 seconds.
Tour Select the
Tour
check box to enable a tour of the selected channels.
Picture Storage
Select the
Picture Storage
check box to take a snapshot of the selected
channel.
To use this function, make sure the following settings are configured:
 The snapshot function is enabled for motion detect alarms in
Main
Menu > STORAGE > Schedule > Snapshot
.
 Select
Main Menu > CAMERA > Encode > Snapshot
, in the Type list,
select
Human Face
.
Sub Screen
Select the check box to enable the function. When an alarm event occurs,
the extra screen outputs the settings configured in
Main Menu >
DISPLAY > Tour > Sub Screen.
Not all models support this function.
To use this function, extra screen shall be enabled.
Buzzer Select the check box to activate a buzzer noise at the Device.
Log Select the check box to enable the Device to record a local alarm log.
Alarm Tone
Select to enable audio broadcast in response to a human face detection
event.
White Light
Select the check box to activate a white light camera to trigger white
light alarm.
Siren Select the check box to activate an audio camera to trigger audio alert.
Click Apply to complete the settings.
5.11.2.2 Searching for Detected Faces
To comply with relevant regulations, the faces have received fuzzy processing.
Select Main Menu > SMART DETECTION > AI Search > Face.

Dahua Technology DH-XVR1B16H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	16 channels
Multi-display modes	4, 8, 9, 16
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	3840x2160, 1920×1080, 1280×1024, 1280×720
BNC input ports	16
BNC output ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	236 mm
Width	260 mm
Height	48 mm
Weight	860 g
